MILITECH SYSTEMS

PCIe Gen 5.0 And Optical Switching Systems

Designed
for

Networks

INDIVIDUALLY MANUFACTURED
Custom Built for long operational business duty lifecycles, MILITECH OPTICAL COMPUTE PLATFORM and SHADOWGEIST NETWORK products fill a privatized supercomputer role for proprietary industry outside the heavily compromised data center sector. Shadowgeist allow for evolution of high-end FRAME systems over extended military lifespan and duty cycle operation, with upgrade and revision planning similar to U.S. Military asset management.

PRIVATE IDENTITY NET
SHADOWGEIST products support SEVEN ALPHA and AM24 Secure Platforms. SHADOWGEIST networks manage user identity and strong communication for real-time logistic systems and communities operating in government and professional security marketplaces. User Strong Identification Protocol (USIP) is required for activation and interface, combined with topology link security encryption.

MSS PLATFORM OPTION
Manifold Spatial Systems are provided only for qualified buyers. Limited by registration and preferred customer list approval prior purchase is required. SHADOWGEIST technology is used in logistics and battle tactics simulations, and may not be purchased or sold for export outside of designated areas and parties by contract. (see The Wassenaar Arangement) FRAME technology is not a consumer technology base. Professional power and electrical grid requiprements apply to all installations.


MILITECH OPTICAL COMPUTE PLATFORM

BASE SYSTEM

9004 Base Node 2024 (2023 4Q)

128 core 256 threads AMD 9754 platform with 3.85 TB M.2 OS drive (Redhat Enterprise Linux 9). Additional NVMe and SATA drive packages based on use case and application role. Platforms are designed to be deployed in clusters for maximum scale using Infiniband NDA technology (400 Gbps optical interchange, with Ethernet over Infiniband applications and hybrid networks). Price is per node, and does not include switch and network fabric, power, and environmental design.

Physical security is a client responsibility due to equipment market value. Qualified site inspection required for delivery.

PART OF THE:

Arclight Signal Environment Suite

Arclight optimizes signal-and-server platform separation for maximum heat and power management in a low profile performance suite, perfect for SOHO and mobile operations activities.

$100,000 USD

Fiber optic backplane Package

400 Gbps network interop for high speed interface with other stations and private networks. Base packages start at $100,000 per site, and are limited to 400 meters between nodes. Additional nodes and sites require quote. Deployment dates subject to availability from hardware provider(s) and market.

Export Restrictions

Limits on Sale and Transfer

Not for export to State of Texas, State of Florida, State of New York, State of Michigan, State of Virginia, State of California, State of Denver, nor State of Wyoming.

Due to foreign unregistered influence and reverse engineering actions by specified competitor sites and employees. Specific threats in 2013-2023 and 2021-2023 prohibit transfer to any firm under color of prohibited user terms and conditions agreement.



MSE PLATFORM:
MANIFOLD SPATIAL ENGINE

$50,000 USD

SHINOBI CLASS

32 thread 9950X Ryzen AM5 Platform
192 GB 5200 MT/s DDR5
1TB M.2 Gen5 OS DRIVE
4TB M.2 Gen4 Support Drive
MSI 4090 24GB GPU

$40,000 USD

BUSHIDO CLASS

32 thread 9950X Ryzen AM5 Platform
24 GB 8000 MT/s onboard DDR5
1TB M.2 Gen5 OS Drive
4TB M.2 Gen4 Support Drive
MSI 4090 24GB GPU

MSE-READY Systems

MSE Agent end-point systems require 10-bit display and AV system I/O for environmental cues and immersive experience of the Manifold Game System environment.

Mainfold Space is a model requiring 20 GB of frame buffer and XTX accelerated performance to execute a computer simulation of space differential than traditional Cartesian Coordinates Systems (CCS) used by OpenGL, DirectX, and VulkanAPI routines. The API for MSE is proprietary to the MSE platform and its licensed manfacturers.

MSE is a cross-platform information protocol, database, and library of software for interpretation of this data rapidly in flight simulation and avionic, environmental, and collision systems not ordinary in consumer entertainment games. MSE nodes are like aerospace and orbital navigation suite applications, including physics and collision detection, particle systems, and intercept trajectory course plotting for real-time actuator roles.

MSE Environmentals

For 50 years, most game systems are represented by dials and counters of conditional performance. MSE Environments are interactive and audio, visual, and tactile feedback of equipment environments suitable for real-world engineering and combat arms experience trials, machine learning, and actuator and expert system training of adaptive software applications for evolution of combat arms assist tools.

MSE equipment is not designed to play older consumer games "better". It is purpose-built for a next-generation simulation grid technology designed and developed in Oklahoma for signal warfare and combined arms combat operations in extreme distance environments. MSE rely on multi-computer mesh network technology.

$100,000 USD

PERSEPHONE CLASS

128 thread 7955WX Threadripper Pro
512 GB 3200 MT/s DDR4
2x 8TB M.2 PCIe
Dual MSI 4090 24GB GPU
6x 10-bit 360Hz Display

$15,000 USD

LETHE CLASS

32 thread 9950X Ryzen AM5
128 GB 5200 MT/s DDR5
2x 1TB M.2 Gen5 10000 MB/s
24 GB 7900XTX GPU
2x 10-bit 360Hz Display

Immersion Related I/O

MSE Rated Systems host client applications necessary to accellerate controller nodes in the manifold System, like metro class controllers for Cellular Data across a city-wide platform, distributing and receiving application services from hardware atached to the overall network.

MSE Optical Cores

MSE systems attached to the optical network nodes, serve as operation stations for MSE flight control and tactical, signal, and engineering services. The platform is based on the 1998 RAIDER AGS frame, not licensed to any other company or hardware vendor for use.
